Learn More About The Big Shax Enclosure

ICD is proud to partner with Big Shax: Indigenous-owned and Canadian-made Insulator Modular Panel System. Big Shax is the solution for more efficient work on pipeline valves, critical pipeline equipment, and dewatering pumps in unforgiving Canadian winters. The impressive solution drastically reduces the environmental impact of current oil and gas industry methods. The Insulated Modular Panel System is an easy-to-use shelter that offers protection from the elements while operating pipeline valves and other critical pipeline equipment in cold weather.

Contact Us
Big Shax Pump Enclosures
Specs bg

Big Shax Enclosures For Dewatering Pumps

Specifications:

  • 25Ft Long X 18Ft Wide X 11Ft To 10Ft High Sloped Ceiling
  • Structural Engineered Insulated Modular Panel System Enclosure
  • High Insulation Value In Walls & Ceilings Of Enclosure
  • 12Ft Wide X 10Ft High Swing Door Opening For Easy Pump Replacement
  • The Skid Base Allows Ease Of Pulling A Fully Assembled Big Shax To The Next Site
  • Two Steel Insulated Doors Meet Oh&S Requirements (3’ Wide X 6’8” Tall)
  • Emergency Backup Heat Source
  • Two Exterior Lights, Two Interior Lights, Two Battery Backup Emergency Lights On The Interior
  • Two 20Lb Fire Extinguishers
  • Enclosure Levelling System

How It Works

The Towable Big Shax Enclosure is designed for mobility and ease of use, featuring a base equipped with two skids and a removable tow hitch for towing. The innovative design allows operators to transport the enclosure directly to the site of essential equipment or pumps without disassembly or disconnection of the pump’s suction or discharge lines. By attaching a loader to the Towable Shax, the operator can easily maneuver the enclosure over a fully operational pump setup.

Big Shax Pump enclosures

Key design features of the Towable Shax include full-width swing doors on both the front and back, ensuring easy access and closure once positioned. The absence of a floor in the enclosure facilitates this straightforward equipment placement. Additionally, the enclosure incorporates collapsible swing arms at its base and a removable tow hitch, enhancing its portability and adaptability to various site conditions.

Once correctly positioned, the operator removes the tow hitch and secures the enclosure by closing the swing doors, leaving only the necessary flip-up doors open to accommodate the pump’s discharge and suction lines, thus maintaining a weatherproof environment within. Depending on the pump’s configuration and discharge direction, the operator can adjust the flip-up doors on the enclosure’s sump side to ensure a snug fit.

The Towable Shax is equipped with a generator to power the enclosure, ensuring it remains a self-contained, highly insulated, and compliant space for its critical equipment. The setup includes interior and exterior lighting and electric heating to prevent equipment freezing. It adheres to OH&S and building code standards, making the Towable Big Shax a versatile and efficient solution for protecting vital operational equipment in various environments.

Specs bg

The Big Shax Enclosure for Pipeline Valves

Specifications:

  • 11ft Long x 11ft Wide x 9ft To 8ft High Sloped Ceiling
  • Fully Opening Hinged Roof With A Manual Winch To Easily And Safely Replace Pipeline Valves Inside Big Shax
  • Structural Engineered Insulated Modular Panel System Enclosure
  • High Insulation Value In Walls & Ceilings Of Enclosure
  • Frame Design With Lifting Apparatus On The Roof For Easy Transport Of Fully Assembled Big Shax To The Next Location
  • Two Steel Insulated Doors Meet OH&S Requirements (3’ Wide x 6’8” Tall)
  • Suitably Sized Electric Heat Source To Heat Valve And Prevent Freezing
  • Two Exterior Lights, One Interior Light, and Two Battery Backup Emergency Lights On the Interior
  • Two 20lb Fire Extinguishers
  • Enclosure Levelling System
